RM3000-A4U patch panel series of optic distribution boxes, which are middle capacity and both side operation, are suitable for central offices connection points in the OAN ,data centers ,local area network etc.
¡ñ Reliable fastening, Stripping and earthling devices for optic fiber.
¡ñ Suitable for LC, LCD, SC, SCD, FC, LCQ, ST and STD adapter.
¡ñ Fit for 19˝rack
¡ñ Accessories make fiber avoid damaging.
¡ñ Slide out design ,easy to access the back. and splicer
¡ñ High-quality steel, beautiful appearance.
¡ñ Maximum capacity: 144 fibers.
¡ñ Can hold 12pcs adapter panel.
Optics performance
¡ñ Insert loss£º¡Ü0.3dB
¡ñ Return loss£º£¾40dB (PC)
£¾50dB (UPC)
£¾60dB (APC)
¡ñ Durability£º£¾1000 Mating ¡ñWavelength£º850nm, 1310nm, 1550nm
Operating condition
¡ñ Operating temperature£º-25¡ãC~+40¡ãC
¡ñ Storage temperature£º-25¡ãC~+55¡ãC
¡ñ Relative humidity :¡Ü85%(+30¡ãC)
¡ñ Air pressure£º70Kpa~106Kpa
Paint & Color
¡ñ Color£º RAL 9005
¡ñ paint£º Comply with ASTM
Package requirement reference
¡ñ All material is ROHS compliant.
¡ñ Dimension 207 x 528 x 430(mm)
¡ñ Weight: 10.6kg
Machine performance
¡ñ Dimension
STANDARD CONFIGURATION
|
RM3000-A4U patch panel accessories |
|
P/N |
Description |
Number |
|
6379920005 |
Abnormity bolt, M6x16 |
4 |
|
6640260001 |
Nylon Locking Tie Wraps , 100©L/2.0©L |
20 |
|
6600510030 |
HEAT SHRINKABLE FIBER OPTIC SPLICE PROTECT |
-- |
|
6190402401 |
Push Pin ¦Õ7.5/¦Õ8.0 |
4 |
|
6190401401 |
Push Pin ¦Õ6.0/¦Õ6.5 |
24 |
|
6260400016 |
spool Cable Routing |
2 |
|
6190100201 |
Splice tray cover , ABS/Black |
1 |
|
6190100202 |
Splice tray body ,ABS/Black |
12 |
|
6260400015 |
Splice holder, ABS/Black |
12 |
|
6260400017 |
Splice buckle, PP/Black |
15 |
|
Notice: ¡°¡ª¡° the number is same to fiber cord number |
|
P/N |
Description |
Capacity |
Dimensions
(H x W x D) |
|
8113901004 |
RM3000-A4U , Bank Panel |
|
177 x 483 x 380 |
|
8113131004 |
RM3000-A4U , 72Ports, fit for ST/FC adaptor |
72/72 fibers |
177 x 483 x 380 |
|
8113211004 |
RM3000-A4U , 72Ports, fit for SC/LCD adaptor |
72/144 fibers |
177 x 483 x 380 |
|
8113221004 |
RM3000-A4U , 36Ports, fit for SCD /LCQ adaptor |
72/144 fibers |
177 x 483 x 380 |
Note: adaptor and pigtail do not been contained, customer needs order individually.
|
|
|
