¡ñ Telecommunications subscriber loop.
¡ñ Fiber to the home.
¡ñ LAN/WAN
¡ñ CATV
¡ñ Different configuration variants of fiber connections
¡ñ Every fiber tray individually accessible for easy fiber access.
¡ñ Bend radius limitation of 30mm for fibers.
¡ñ 1 lockable wardrobe door
¡ñ Various top or bottom cable entry possibilities
¡ñ Wall mounting at 4 points
¡ñ Robust steel construction
¡ñ Powder coated black(RAL9005)
¡ñ Compact outer dimensions.
¡ñ maximum capacity: 48 fibers.
¡ñ can hold 4pcs adapter panel.
Optics performance
¡ñ Insert loss£º¡Ü0.3dB
¡ñ Return loss£º£¾40dB (PC)
£¾50dB (UPC)
£¾60dB (APC)
¡ñ Durability£º£¾1000 Mating
¡ñ Wavelength£º850nm,1310nm,1550nm
Paint & Color
¡ñ Color£º RAL 9005
¡ñ paint£º Comply with ASTM
Operating condition
¡ñ Operating temperature£º-25¡ãC~+40¡ãC
¡ñ Storage temperature£º-25¡ãC~+55¡ãC
¡ñ Relative humidity£º¡Ü85%£¨+30¡ãC£©
¡ñ Air pressure£º70Kpa~106Kpa
Package requirement reference
¡ñ All material is ROHS compliant.
¡ñ Dimension 353 x411 x146(mm)
¡ñ Weight : 5.1kg
Machine performance
¡ñ Dimension
STANDARD CONFIGURATION
|
WM2000-A patch panel accessories |
|
Model Number |
Product name |
Number |
|
6640260001 |
Nylon Locking Tie Wraps , 100©L/2.0©L , |
32 |
|
6600510030 |
Heat Shrinkable fiber optic splice protector, |
-- |
|
6190920702 |
Buckle stuff, ¦Õ20,NBR,fit dimension: ¦Õ20-¦Õ50 |
4 |
|
6190401401 |
Push Pin¦Õ6/¦Õ6.5 |
8 |
|
6190100206 |
Splice tray cover , ABS/Black , |
1 |
|
6190100208 |
Splice tray body ,ABS/Black , |
2 |
|
6260400015 |
Splice holder ,ABS/Black , |
4 |
|
6260400017 |
Splice buckle, PP/Black , |
4 |
|
Notice: ¡°¡ª¡° the number is same to fiber cord number, |
|
P/N |
Description |
Capacity |
Dimensions
(H x W x D) |
|
8122001001 |
WM2000-A , Bank Panel |
|
298 x 356 x 91 |
|
8122131001 |
WM2000-A , 6Ports, fit for ST/FC adaptor |
24/24 fibers |
298 x 356 x 91 |
|
8122211001 |
WM2000-A , 6Ports, fit for SC/LCD adaptor |
24/48 fibers |
298 x 356 x 91 |
|
8122221001 |
WM2000-A , 6Ports, fit for SCD /LCQ adaptor |
24/48 fibers |
298 x 356 x 91 |
Note: adaptor and pigtail do not been contained, customer needs order individually
|
