Application   RM3000-DBA distribute box is a series of optic distribution boxes, which are middle capacity and both side operation, are suitable for central offices connection points in the OAN ,data centers ,local area network etc.      Features ● Reliable fastening ,Stripping and earthling devices for optic fiber, ● Suitable for SC/LCD, SCD, MPO adapter, ● Accessories make fiber avoid damaging, ● High-quality steel, beautiful appearance, ● Can be fixed on the RM3000 series box.      Main performance Optics performance ● Insert loss：≤0.3Db ● Return loss： ＞40dB (PC)                            ＞50dB (UPC)                            ＞60dB (APC) ● Durability：＞1000 Mating ● Wavelength：850nm,1310nm,1550nm   Chemical performance ● Plastic parts combustibility meets GB51697-85 standard , ● All material can be exist each other, ● All material is no harmful to body ,   Operating condition ● Operating temperature：-5°C~+40°C, ● Storage temperature：-25°C~+55°C, ● Relative humidity：≤85%（+30°C）, ● Air pressure：70Kpa~106Kpa , Paint & Color ● Color： RAL 9005 ● paint： Comply with ASTM , Machine performance ● Dimension      Accessories STANDARD CONFIGURATION RM3000-DBA patch panel accessories Model Number Product name Number 6640260001 Nylon Locking Tie Wraps , 100㎜/2.0㎜ 10 6190501151 Blank Dummy-SC/LC duplex 6 6190503151 Blank Dummy-SC duplex 6 6190401401 Push Pin φ6.0/φ6.5 2      Order Information P/N description                      Dimensions       (H x W x D)       5120815065 RM3000-DBA ,fit for SCD-6 adaptor ,multi core cable assembly 29.5 x 130x116 5120814063 RM3000-DBA ,fit for SC/LCD-6 adaptor ,multi core cable assembly 29.5 x 130x116 Note: adaptor and pigtail do not been contained, customer needs order individually.
