Innovative design JX1000-B is an arc and horizontal type with one hinge in one side and open in another side. Two pieces of insert plates and fixing bolts are used to fix and seal FOSC. The FOSC is suitable for protecting fiber cable splices in straight-through and branching applications. It can be placed in underground, aerial, wall-mounting, handhole-mounting and duct-mounting applications. Based on an advanced formula, the plastic parts are made of injection-molded, high-strength engineering plastic PC by numerical control equipment, therefore effectively prevent products from aging caused by coldness, heat, oxygen and ultraviolet radiation. The strong housing and main components provide fire resistant, waterproof, and quakeproof while protecting splice closure during pulling, torsioning and impacting.
¡ñ Advanced internal structure design;
¡ñ Easy to re-enter, it never requires re-entry kits.
¡ñ Fiber optic splice tray is designed in SLIDE-IN-LOCK and its opening angle is above
¡ñ 90 degree. Therefore it is easy and fast to increase and reduce FOST. (Note: All of the above features make it easy and convenient for installation, maintenance and reuse. If required, the earthing deriving device can be installed on the housing of FOSC for deriving metallic parts of fiber cable for earthing connection. Pressure testing valve can be installed as well for pressure testing and sealing testing after injection air.)
Jx1000-B consists of one set of elastic seal fitting, which, based on an advanced formula, is made of injection-molded, high quality elastic sealing material by numerical control equipment. It is installed between FOSC housing and insert plates.
Sealing is achieved by using 2 pieces of innovative insert plates and bolts, therefore easy for installation. The most strongpoint is that the insert plates and housing are made of injection-molded, high-strength engineering plastic PC by numerical control equipment. They, together with elastic seal fitting, can be shrinking and dilating at the same rate under violent changes of ambient temperature, therefore the closure ensures long-term reliability and sealing performance.
¡ñ The capacity of bunchy FOST 019 is 12 cores.
¡ñ The capacity of bunchy FOST 020 is from 12-24 cores.
¡ñ Quantity of bunchy FOSTs and heat shrinkable protective sleeves are to be determined according to the total capacity of FOSC. (Note: each bunchy fiber has one core after fusion splicing, which needs one piece of bunchy heat shrinkable protective
sleeve)
¡ñ Ribbon FOST 021 can accommodate 3 pieces of ribbon heat shrinkable protective sleeves. (Note: each ribbon fiber has multi-cores after fusion splicing.)
¡ñ Outside dimension: (L x W x H):396mm x 190mm x 126mm
¡ñ Jx1000-B consists of one set of elastic seal fitting with 6 inlet/outlet ports, diameter of 2ports is 20mm, diameter of other two ports is 16 mm, diameter of remaining two ports is 13 mm. The inlet/outlet ports could be decided according to quantity and diameter of fiber cables to be actually installed, the corresponding port plugs should be taken out. Max. 6 pieces of fiber cable can be inserted.
¡ñ JX1000-B3 can accommodate 1-4 ribbon FOSTs with 3 pieces of ribbon heat shrinkable protective sleeves per tray. 4 cores, 6 cores, 8 cores or 12 cores per ribbon heat shrinkable protective sleeve are available for customers' selection. The following can be configured according to capacity of FOSC and number of cores of each ribbon fiber of fiber cable to be actually installed.quantity and number of cores of ribbon heat shrinkable protective sleeve In this case, buffer tube is necessary to be ordered and can hold max 3 pieces of ribbon fibers .
¡ñ The installation accessories provided with the FOSC: seal tape, insulation tape, 3 pieces of special wrenches, hanging hook, abrasive cloth, earthing wire, nylon tie, labeling paper, measuring paper, desiccant. Accessories for customers' selection: earthing deriving device, buffer tube for ribbon fiber, buffer tube for bunchy fiber and pressure testing valve (please refer to the installation accessories).
